Application

• Pulse isolator for the supply of NAMUR sensors.
• Pulse isolator for the detection of mechanical contacts.
• One input signal can be used on two separate outputs.
• A cable error alarm can be detected on a separate output.

Technical characteristics

• PR5202A1 and 5202A2 have relays with change-over contacts or open NPN collectors.
• PR5202A4 has 4 SPST relays, which are activated simultaneously two and two. Each relay can be programmed to the function N.O. or N.C.
• Inputs, outputs and supply are floating and galvanically separated.
• 5202 is designed according to strict safety requirements and is therefore suitable for application in SIL 2 installations.

Mounting / installation

• Mounted vertically or horizontally on a DIN rail. Up to 84 channels per meter can be mounted.
