Non-Contact Level Transmitters – OPTIWAVE 1010
Sosyal Medya'da Paylaş
Ürün Açıklaması
Radar (FMCW) Level Transmitter for bypass chamber and magnetic level indicator

  • Device welded to a bypass chamber with an optional IP68 level indicator (BM 26 Advanced) – for the continuous measurement of clean liquids
  • Device is configured and ready to use before it leaves the factory
  • Measuring distance up to 8 m / 26.2 ft
The OPTIWAVE 1010 is a non-contact FMCW radar welded to a bypass chamber with an optional IP68 level indicator (BM 26 Advanced). It continuously measures the distance and level of clean liquids.

Highlights

  • 2-wire, loop-powered, HART®, 6 GHz Radar (FMCW) Level Transmitter for clean liquids
  • Welded to a bypass chamber or BM 26 Advanced MLI
  • Device is configured and ready to use before it leaves the factory
  • Adjustments possible using HART® communication / DTM / DDs
  • ±5 mm / 0.2¨ accuracy
  • Measuring distance up to 8 m / 26.2 ft
  • Metaglas® or Metapeek seal (dual process seal system)
  • Max. process conditions +150°C / +302°F and 40 barg / 580 psig
  • No minimum dielectric constant when using a float
Industries

  • Chemical industry
  • Power
  • Water & Wastewater
  • Automotive
Applications

  • Raw material storage
  • Water hammer arresters
  • Liquefied gas
  • Hydraulic oil
